MCL21Ci LBL BK US
mC-Label2 · Barcode Label Printer · Adjustable Label Width with Max 2” · Tearbar · 300 dpi · USB-C with Power Delivery for iOS / Android / Windows · Ethernet (LAN) · SteadyLAN · CloudPRNT · Peripheral Hub · Black · Ext PS Included
The mC-Label2 multifunction printer by Star Micronics delivers high-resolution labeling in a compact 2-inch design, perfect for tight spaces and small-format prints. It features a front-loading, front-exit design that fits neatly under counters or shelves and supports linerless labels, die-cut labels, receipts, and continuous paper with sharp 300 dpi clarity. This Cloud Ready label printer works with Star Micronics Cloud Services, StarIO.Online, and Label Builder for template-based printing and device management. With One Touch Label, users can store and print up to three static designs directly from the printer, even without an internet connection. Compatible with iOS, Android, and Windows, the mC-Label2 is available in wired and wireless models to fit a wide range of retail, foodservice, healthcare, and cannabis applications.
MCL21Ci LBL BK US
MCL21Ci LBL BK US — Complete Specifications
| Specification | Detail |
|---|---|
| Printer Method | Direct Thermal |
| Print Resolution | 300 dpi (11.8 dots/mm) |
| Print Speed | Up to 180 mm/sec |
| Paper Width | 25 mm – 60 mm |
| Print Width | 15 mm – 56.9 mm |
| Roll Diameter | Max. φ102mm |
| Paper Thickness | 53 – 154μm (Varies depending on paper type) |
| Media Types Supported | MCL21 Models: Linerless labels (sticky/permanent), Die-cut, Continuous, Thermal receipt MCL21 LBL Models: Die-cut labels, Thermal receipt |
| Top Margin | 3 mm (default), 11 mm supported |
| Cut Method | MCL21 Models: Guillotine style (partial/full cut) MCL21 LBL Models: Tear bar |
| Interfaces | MCL21 X4 (CWBI) Models: USB-C as Ultra-C, USB-A, LAN, WLAN, Bluetooth (MFi-certified) MCL21 (CI) Models: USB-C as Ultra-C, USB-A, LAN, Optional WLAN |
| Emulation | StarPRNT |
| Flexible Connection | StarXpand SDK, StarPRNT SDK, Star PassPRNT™, CloudPRNT™, CloudPRNT Next, Various drivers, Star Quick Setup Utility®, SteadyLAN™ |
| System Compatibility | All major operating systems: iOS (MFi on Bluetooth models), macOS, Android, Windows, Linux |
| Cloud Compatibility | CloudPRNT Next, CloudPRNT, StarIO.Online, Star Micronics Cloud Services, Label Builder |
| One Touch Label | Store and print up to 3 static label designs offline |
| Paper Loading | Front loading and drop in |
| Paper Exit | Front exit |
| Sensors | MCL21 Models: Cover open, paper end, GAP/black mark, hold print (taken), paper jam, cutter home position MCL21 LBL Models: Cover open, paper end, GAP/black mark |
| Dimensions | 98 x 185 x 145.5 mm (W x D x H) |
| Weight | Approx. 1.6 kg (main unit only) |
| Ingress Protection Rating | IP22 |
| Included Accessories | Power supply, AC cable, USB cable (A to C), easy setup guide, safety guide |
| AC Adapter | PS65AT-24A |
| Model Variants | mC-Label2 Models (all-media): MCL21Ci, MCL21CWBI mC-Label2 LBL Models (die-cut & receipt only): MCL21Ci LBL, MCL21CWBI LBL |
| Operating Temperature | 5°C to 45°C |
| Humidity Range | 10% to 90% RH (non-condensing) |
| Options | Replacement Parts: 2in1(Cutter & Platen), Cutter Unit, Platen Roll Unit Peripherals: Star Barcode Scanners, Wireless LAN Unit (MCW10) |
| Warranty | 2-Year Limited Manufacturer Warranty (US & Canada) |
| Warranty Options | SWAP-A-STAR® Warranty Program (US) EXTEND-A-STAR® Extended Warranty Program (US and Canada) |
Source: official Star Micronics product data.
8 Highlights
Compact Front-Loading Design
Fits under counters or against walls with front paper loading and exit
300 DPI Resolution
Prints sharp text, barcodes, and small-format labels with high clarity
Flexible Media Support
Prints on linerless, die-cut, continuous labels, and receipts (MCL21Ci & MCL21CBWI models only); die-cut only printer also available
One Touch Label
Stores and prints up to three pre-designed labels without a network connection
Paper Width Range
Supports media from 25 mm to 60 mm wide
Connectivity
X4 Models: "Ultra-C" USB-C, LAN, WLAN, USB-A (for peripherals), and Bluetooth; Ci Models: "Ultra-C" USB-C and LAN connectivity with USB-A for peripherals
Apple MFi-Certified
Bluetooth pairing with iOS devices on X4 models
Cloud-Connected
Supports StarIO.Online, Label Builder, and CloudPRNT Next
