MG-TUDB Pole Display
Pole Display For MG-T12/30/60UDB Scales
Enhance precision and efficiency at the point of sale with the mG-TUDB Pole Display from Star Micronics. This optional accessory, designed exclusively for the mG-TUDB models of Star’s POS scales, offers clear, high-contrast visuals of weight (lbs, kgs, oz), ensuring transparency and boosting customer trust. The digital pole display is conveniently powered directly by the scale, which simplifies setup and usage without the need for additional power sources. Its versatile design includes adjustable viewing angles, making it ideal for retail, grocery, deli, and cannabis environments.
MG-TUDB Pole Display
MG-TUDB Pole Display — Complete Specifications
| Specification | Detail |
|---|---|
| Product Type | Pole Display |
| Compatibility | Only compatible with the mG-TUDB series scales |
| Connectivity | RS232 serial port |
| Power Source | Powered via the scale |
| Display Type | Backlit LCD for clear visibility |
| Weight | 0.44 Kg (0.97 lbs) |
| Package Dimensions | 535 x 157 x 143 mm (21.1 x 10.1 x 5.6 in) |
| Installation | Field-installable with included hardware |
| Viewing Angles | Adjustable at 0/90/180/270° |
| Included in the Box | • Pole display • Stainless-steel pole • Bottom bracket • 4 screws • Plastic cover • Installation instructions |
Source: official Star Micronics product data.
5 Highlights
Serial Connectivity
Connects via the RS232 serial port, ensuring reliable data transmission (mG-TUDB model scales only).
Power Efficiency
Draws power directly from the scale, reducing cable clutter and energy use.
High-Contrast Display
Features a clear, high-contrast display that enhances readability in any environment.
Adjustable Viewing Angles
Can be fixed at 0/90/180/270° relative to the front of the scale for optimal viewing.
Versatile Use Cases
Ideal for retail settings like groceries, butcher shops, and delis.
