SK1-311SF4-Q-M-SK-SP
SK1 · Kiosk 3" for Sticky Paper · USB/Serial · Ext PS Needed
The SK1-311 SK is a 3-inch linerless label kiosk printer that provides dependable, low-maintenance service with a 200mm/sec fast print speed and a 203 dpi resolution. Repositionable thermal labels stick to virtually any surface and are easy to remove and reapply, leaving no residue. Linerless sticky labels are an alternative to silicone-lined labels or tape and are more eco-friendly, ideal for the food, beverage, and travel industries or any self-service application. The SK1-311 SK kiosk printer comes in standard format (horizontal orientation). All SK1-311 models come with RS-232C and USB interfaces which integrate with many commonly used kiosk solutions.
SK1-311SF4-Q-M-SK-SP
SK1-311SF4-Q-M-SK-SP — Complete Specifications
| Specification | Detail |
|---|---|
| Printer Method | Direct Line Thermal Printing |
| Print Speed | Max 200mm/sec |
| Paper Width | 80mm, 83mm |
| Print Width | 72mm, 80mm |
| Paper Roll Holder | Max 83mm |
| Paper Specifications | Dimensions: Max.φ83mm Core Diameter: Internal φ25.4mm x External φ29.4mm |
| Resolution | 8 dots/mm (203 dpi) |
| Font | 8x16, 12x24 dots |
| Character Types | ASCII Characters: PC437/850/852/857/858/863/865/866/860/862/864/737 WPC1252/1252_2/1254/1250/1251/PC1253 |
| Bar Code | UPC-A/E, JAN13/8, CODE39, ITF, CODABAR, CODE128, GS1 Databar Omni-directional, Truncated, Limited, Stacked, Stacked Omni-directional |
| 2D Bar Code | QR, MicroQR, MaxiCode, MicroPDF417, PDF417, DataMatrix |
| Interface | USB & Serial (RS-232) |
| Auto-Cutter | Full and partial cut (command selectable) |
| Operating Temperature | 5oC to 40oC |
| Optimal Print Quality Temperature | 5oC to 40oC |
| Operating Humidity | 20 to 85% (non condensing) |
| Operating Voltage | DC 24V |
| External Dimensions | 127(W) × 129.2(D) × 73.6(H)mm |
| Weight | Approx. 630g (without paper roll) |
| Reliability MCBF (Printer) | Print Head Auto-Cutter Life 150 Million Lines 100km or more 1M cuts or more (with recommended paper) |
| Safety Standard | CE, FCC, VCCI(Class A) / RoHS/ UL |
| Warranty | 1 Year Warranty for Parts and Labor |
Source: official Star Micronics product data.
4 Highlights
High Speed
Max 200 mm/sec
High Reliability
MCBF: 150 Million Pulses; Auto Cutter: 1+ Million Cuts
Self-Service
Perfect for any self-service application requiring repositionable linerless sticky labels
Eco-Friendly
Linerless labels have no coated paper backing which cuts down on waste
