TSP100III
Introducing the TSP143III, the trusted thermal receipt printing solution tailored for businesses of all sizes, offering seamless installation, exceptional print quality, and a USB-A port to charge mobile devices on the go. Boasting USB, Bluetooth, Ethernet (LAN), and wireless (WLAN) connectivity, this versatile printer is ideal for businesses in the retail, hospitality, and cannabis industries. It includes access to futurePRNT receipt customization software and offers a wide range of optional accessories, able to adapt and excel in any business setting. This all-inclusive package comes with everything you need to begin: an internal power supply, power cables, mounting kits, and a starter paper roll, making it the perfect addition to any mPOS bundle. Get your business to the next level with the winning performance and adaptability of the TSP143III thermal receipt printer.
TSP100III
TSP100III — Complete Specifications
| Specification | Detail |
|---|---|
| Printer Method | Direct Line Thermal |
| Print Speed | 43 RPM (Receipts Per Minute) |
| Printer Case Color | Ultra White or Gray |
| Models Available | Auto-Cutter with Emergency tear bar on the front guide |
| Print Resolution | 203 dpi (8 dots per mm) |
| Font Size | 12 X 24 |
| Character Set | ANK 95, 32 Int 128 Graphic plus Chinese, Japanese, Korean, Taiwanese |
| International Code Pages | Star Mode=48 |
| Bar Codes | Extended barcode functionality - 9 versions / PDF 417, Maxicode Option |
| Line Spacing | 3 mm or 4 mm or programmable |
| Top Margin | 11 mm default |
| Paper Specifications | Width: 80mm standard, 58mm with paper guide Thickness: 0.053 ~ 0.085 mm Roll Diameter: Up to 83 mm Easy - Load: "Drop-In & Print" Paper Out Sensor: Standard Paper Low Sensor: N/A Maximum Print Width: 80mm paper = 72mm, 58mm paper = 50.8mm |
| Auto Cutter | Guillotine (Partial Cut Only) |
| Cover Open Sensor | Yes |
| Logo Store Capacity | Unlimited |
| Multiple Copy Support | Supported through FuturePRNT Software |
| Journal Capability | Supported through FuturePRNT Software |
| Label Support | N/A |
| Power Supply | Internal with power cable supplied |
| Drivers Available | Windows 10, Windows 8.1, Windows® XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, POSReady2009, OPOS™, JavaPOS™, USB Vendor Class, CUPS, Mac, Mac OS X, Linux™, StarPRNT SDK with support for iOS and Android |
| Digitally Signed (WHQL) | Yes |
| Swappable Interfaces | N/A |
| Connectivity | TSP100IIIWLAN (802.11b/g/n with 2.4GHz) TSP100IIIBi - Bluetooth iOS (Apple MFi-certified) TSP100IIILAN - Ethernet (10/100BaseT, UTP) with 1 m cable included TSP100IIIU - USB with 1.8 m cable included Virtual Serial Port to USB - Supported through FuturePRNT Software (TSP100, TSP100PUSB, TSP100LAN) Virtual Serial Port to LAN - Supported through FuturePRNT Software (TSP100LAN) |
| Emulation Modes | Star Mode SDKs (Raster only) |
| Peripheral Drive Circuit | 2 circuits, (24V max. 1A), 1 compulsion input |
| Power Consumption | Average 1.6 Amp. Printing, 0.1 Amp. Standby |
| Operating Conditions | Temperature: 5oC to 45oC Humidity: 10% - 90% RH (without condensation) |
| Storage Conditions | Temperature: -20oC to 60oC Humidity: 10% - 90% RH |
| Dimensions | 142 X 132 X 204 (w x h x d)mm |
| Weight | TSP143IIILAN – 1.73kg TSP143IIIBi – 1.53kg TSP143IIIW – 1.72kg TSP143IIIU – 1.72kg |
| Safety Standards | UL, C-UL, TuV, FCC, VCCI, EN55022, CE |
| Reliability MCBF | 60 Million Lines Printhead: 100km Auto Cutter: 2 Million Cuts |
| What's in the Box | Wall Mount Bracket, 58mm Paper Guide, 6ft Power Cable, Power Switch Cover, Easy Setup Guide, Installation CD with Drivers and FuturePRNT Receipt Design Software Auto Reverse Text Output Software (Power Cable not included with PUSB versions), Interface cables are included with the LAN and USB models |
| Warranty | 2 Year Limited Manufacturer Warranty (US & Canada) |
| Options | Splash Proof Cover (SPC-T100) Vertical Stand (VS-T650) Kitchen Buzzer (BU01-24-A) Swap-A-Star Extended Warranty Program (US) Extend-A-Star Extend Warranty Program (US and Canada) |
Source: official Star Micronics product data.
8 Highlights
All In One Box
All accessories included in the box with the printer
High Speed
Can print 45 six inch Receipts per Minute (250mm/sec)
High Reliability
MCBF: 60 Million Lines; Guillotine Auto Cutter: 2 Million Cuts
Small Footprint
Save precious counter space
Embedded Power Supply
No more power brick, saving even more counter space
“Drop In & Print” Paper Loading
Clamshell design allows for very fast and easy paper loading
Recessed Cable Connections
Helps protect cables from being damaged on the counter top
Horizontal or Vertical Orientation
Use the printer in the orientation that suits you best. An optional eye-pleasing vertical stand (VS-T650) is available for vertical operation.
